Automotive Semi Downdraft Spray Booth Get latest price

Specifications

• Power supply: 415V / 3-phase
• Cabin: 50mm premium interlocking EPS panel, Surfmist finish
• Base: Existing concrete floor, no excavation required
• Inlet fan: 760mm centrifugal backward curved impeller, 5.5kW, variable speed drive
• Exhaust fan: 860mm lightweight nylon, 45° pitch, 4kW 3-phase motor
• Inlet filters: 600G fibre inlet filter
• Exhaust filters: 3D Polycomb Paint Pocket
• Lighting: LED 6000K daylight tubes
• Control panel: AS/NZS 4114 compliant, semi-auto analogue
• Fuel type (heated): LPG or Natural Gas

Features

• Positive pressure airflow system
• Energy efficient variable speed drive on inlet fan
• Trifold entry doors with laminated glazed glass
• Direct fired gas heating available (heated version)
• AS/NZS 4114 compliant control panel with pre and post purge timers

Applications

• Automotive spray painting and refinishing
• Body shop and collision repair
• Light to medium volume finishing work

Why Choose This Product

• Cleaner finishes with positive pressure airflow
• No pit or excavation — installs on existing concrete
• Available heated or non-heated
• 100% Australian Made & AMAG Certified
• Backed by MN Spraybooths' sales and service team
