PTO Wood Chipper | TP 230

Name: PTO Wood Chipper | TP 230
Brand: Chipstar Australia

Supplier: Chipstar Australia

1/4

PTO Wood Chipper | TP 230

Linddana TP 230 PTO Wood Chipper

In Stock

Suitability

If you need to process large 230mm wood into chips for either cart-hauling or roadside deposit, the TP 230 PTO is suited to your needs.

Features

processes organics up to 230mm in diameter
hydraulically fed disc chipper
90 degree funnel for cart or roadside deposit
45 degree cuts allow misshaped and crooked tress can be processed problem-free
automatic feeding â„…TP Pilot Stress Control System
3 type A silver breakers
Trailer Road Ready
Two anvils in Hardox 400

Usability

The TP 230 PTO is ready for the road, attach to a trailer and go! Perfectly matched for depositing processed chips either directly into a cart, or on the roadside.

Technical Data
Max Wood Diameter	230mm
Max Opening	H x W = 230 x 240mm
Operation	Return/forward/stop of feed rollers through operating bar (yellow)
Stress Control System	TP 100 Automatic feeding
Chipper Principle	Disc
Cutting Angle	45 degrees
Hopper Placement	90 Degrees to the side
In Feed	2 hydraulic feed rollers, spring compressed of 1 spring 8mm
Feed Rollers	Horizontal
Rotordisc – Diameter	760mm
Rotordisc – Weight in kg	149
Number of Knives	3pcs.
Chip Size	12-19mm
Anvil/Counter Steel	1 Horizontal and 1 Vertical
Power Required	37-90kw (50-120hp)
PTO RPM	540 rpm or 1,000rpm/min.
PTO Shaft	Walterscheid 2400 series with freewheel, length = 560mm
3-Point Linkage	Category 2
Chip Capacity	10-15 m³/hour (Experience numbers by manual operation)
Max allowable pressure on coupling	500 kg
Weight	990 kg
Tool Kit	Yes

Extra Equipment
Extended Ejector Spout	500 mm vertical 1,500 mm horizontal
Silverbreakers	Type B – are used if extra requirements for chip quality is needed. Opening max. 35×40 mm
TP Winch	For wood feeding – the winch is towed by the wood chippers hydraulic system
Light Bar	Light bar with complete set of rear lights
