All the modules can simply be added to the assembly during or after installation with ease. The range has been designed to minimise metal components and utilise Grivory Polymer GV-6H, a synthetic low weight material with improved design and shaping options. Grivory Polymer GV-6H contains 60% glass fibre, resulting in impressive strength figures, rigidity and surface quality.
Automatic drains are available in all sizes, 0, 1, 2 and 4 Metal bowls fitted with a sight glass are available for all filter and lubricator sizes Activated Carbon filters available on request
| CONSTRUCTION MATERIALS | ||
|---|---|---|
| Main body | Grivory GV – 6H / Die Cast Aluminium | |
| Knob | Acetal ( POM) | |
| Bowl | Polycarbonate & Metal available | |
| Facia panels | ABS Polymer | |
| Filter Element | 5 μm standard element: | Polymerised Cellulose |
| 0,3 μm fine filter element: | Paper / Aluminium | |
| 0,01 μm micro filter element: | Borsilicate / Aluminium | |
| Active carbon filter: | Active carbon | |
| Seals | NBR | |
| Springs | Galvanized steel & stainless steel | |
| Diaphragm | Brass – NBR – PA6 | |
| Valve internals | Ms / NBR / brass | |
To contact Tecnair about Filter Regulator Lubricator | Eco Hi-Tec Series use Get a quote.
