Boom Sprayer | 2500 Trailed Sprayer

Name: Boom Sprayer | 2500 Trailed Sprayer
Brand: Frasers Machinery

Supplier: Frasers Machinery

2026 HARDI RANGER 2500 trailed sprayer configured with an 18-meter EAGLE boom, TurboFiller chemical hopper, and HC 5500 controller is a high-performance, heavy-duty setup optimized for demanding field conditions.

Receive 1-3 days from order

Specifications

Key Features

Component	Standard Specifications
Tank Capacity	2,500 Liters net liquid volume (plus a 250L Rinse Tank)
Boom Width / Type	18 Meter EAGLE rugged 2D structure with self-stabilizing suspension
Controller Unit	HC 5500 Rate Controller featuring automatic on-the-go rate regulation
Chemical Transfer	TurboFiller high-capacity induction hopper (usually 35L)
Pump Output	HARDI 364 grease-sump diaphragm pump providing 194 L/min
Clearance & Track	70 cm ground clearance with an adjustable axle (1.5m to 2.3m)

EAGLE 18m Boom Structure: Engineered explicitly for high driving speeds and rough conditions. It features a self-stabilizing trapeze coil-spring suspension to manage horizontal movement and non-directional spring-loaded breakaways to prevent structural damage.

HC 5500 Rate Controller: A well-proven, advanced application computer that automatically regulates application rates based on ground speed. It provides active status parameters, supports up to 98 operational registers, and connects directly to site-specific application maps.

TurboFiller Chemical Hopper: Utilizes a TurboDeflector system to mix and dissolve both liquid and dry powdered chemicals thoroughly before pumping them into the main tank, minimizing operator exposure.

Liquid System & Filtration: Built with a logical manifold system for simplified filling, agitating, and rinsing operations. Employs a multi-stage filtration setup—including a self-cleaning CycloneFilter—to eliminate nozzle blockages.
