Vertical Conveyor | HI100 Get latest price

Features of this product

• Sidewall belts have corrugated sidewalls and transverse cleats to provide pockets, which can carry all kinds of bulk materials from floury material up to 400 mm lumps. Sidewall belt has a cross rigid base belt, which can be deflected from horizontal to incline without bowing or sagging. As the stretch of the belt is minimal, take-up is typically screw type located in tail end.
• Our know-how of bulk materials handling is based on solid experience of various materials and all parts of a complete conveying system. Expertise has gained depth from thousands of references all over the world. Continuous product development has resulted in an exceptionally extensive selection of conveyor components and you will get all parts and services rapidly and effortlessly from the same supplier.
• Due to modular structure HI100 High Incline Conveyor can be quickly assembled at site. It is delivered in pre-assembled modules with main components installed. Modules can be packed in standard containers, which protect the equipment before installation and allow easy transportation to site.
• HI100 High Incline Conveyor is delivered with high quality mesh guards to allow safe use of the machine and visibility for maintenance. Standard delivery includes belt misalignment switches and rotation detector to protect sidewall belt. Emergency switches are included according to EN620. Chutes are available as options and include blockage detectors.

Specifications of this product

We have various models and specifications in our range. These details are for the Vertical Conveyor | HI100. Get in touch to let us know your requirements so we can quote you on a product that best suits your needs.

• Capacity: t/h 100 - 2000
• Total lift: m 10 - 100
• Lift angle: deg 20 - 90
• Belt width: mm 400 - 2400
• Sidewall height: mm 40 - 630
• Cleat height: mm 20 - 600
• Roof and wind covers: Option
• Loading / discharge chute: Option
