Tapping Machine | CHT635LPGet latest price

Features of this product

• Drive as close to cutter as possible
• Auto feed gearbox and motor optional
• Pneumatic or hydraulic operation
• Internally pressure balanced system
• Lightweight construction

Specifications of this product

We have various models and specifications in our range. These details are for the Tapping Machine | CHT635LP. Get in touch to let us know your requirements so we can quote you on a product that best suits your needs.

• Minimum tapping hole diameter: 50mm 2”
• Maximum tapping hole diameter: 305mm 12”
• Maximum pressure: 34 bar 500 p.s.i
• Maximum operating temperature: 200° C 392° F
• Spindle bar travel: 635mm 25”
• R.P.M: Min: 5 Max: 40
• Drive – Pneumatic: 4.0 Hp 3.0 Kw
• Drive – Hydraulic: 5.0 Hp 3.7 Kw
• Feed – Pneumatic (optional): 1.5 Hp 1.11 Kw
• Feed Hydraulic (Optional): 2.2 Hp 1.64 Kw
• Air Consumption / supply required: 98 s.c.f.m 2.69 m3/m
• Hydraulic supply required @ 1050 p.s.i: 50 L/min 13 gal/min
