Subsea Pressure Regulator | SS691Get latest price

With the balanced main valve option it can provide stable control under varying inlet pressures and cope with higher flow rates.

Product Features:

• SUITABLE FOR DEEPER WATERS: Can operate at depths of up to 3,000 metres (10,000ft).
• ANTI-TAMPER LOCKING CAP: Cap prevents unwanted pressure adjustments to regulator.
• MP35N VALVE SPRING: Very high strength with excellent corrosion resistance for sea water ref options.
• OPTIONAL REMOTE OPERATION: Optional ROV handwheel or subsea multi-turn electric actuator

Product Specifications:

• Max. Rated Inlet Pressure: 1,034 bar (15,000 psi)
• Outlet Ranges: Up to 690 bar (10,000 psi)
• Design Proof Pressure: 150% max. working pressure
• Seat Leakage: In accordance with ANSI/FCI 70-3
• Weight: 10.5kg (23.1lbs)

Product Materials:

• Body and Bonnet: AISI 316/316L Stainless Steel (UNS S31600/S31603)
• Main Valve Pin: AISI 316/316L Stainless Steel (UNS S31600/S31603) or Ceramic
• Seat: Ceramic
• Valve Spring: MP35N (UNS R30035)
• Piston: AISI 316/316L Stainless Steel (UNS S31600/S31603)
• Locking Cap: AISI 316/316L Stainless Steel (UNS S31600/S31603)
• O-Rings: NBR
• Loading Spring: MP35N (UNS R30035)
