- Kohler 4 Cyl. Turbo Diesel/75 Hp
- Transmission: Hydrostatic
- Maximum Speed: 25 mph
- Total Unladen Mass: 10,700 lbs.
- Delivery Pressure (psi-gal/min) 3,045/25
- Hydraulic Pump: Gear
- Fuel Capacity: 18 gal.
- Hydraulic Oil Capacity: 19 gal.
- Dimensions: 12’8″ x 6’1″ x 6’5″
- Turning Radius over Tires: 11’0″
- Ground Clearance: 10′ 0″
- Wheelbase: 8’0″
- Tires: 12-16.5
- Boom Sections: 2
- Brakes: Dry Discs
- 4WD/ 3 Steering Modes
- Reverse Shuttle: Finger Touch
STANDARD EQUIPMENT
- Heat/AC
- Enclosed Cab
- Cab: FOPS II ROPS
- 2 Floating Forks
- Tac-Lock for Attachments
- Low Pivot Boom
- Ground Engaging Boom
- Electromechanical Joystick
- ASCS Overload Protection System
- Auxiliary Hydraulic Service on Boom
- Pedal Inching-Control
- Automatic Parking Brake
- Permanent Four-Wheel Drive
CYCLE TIMES (2k rpm)
- Lift Up: 10.07s
- Lift Down: 9.23s
- Lift Up & Out: 17.69s
- Lift Down & In: 13.67s
- Reach Out: 8.05s
- Retraction: 5.18s
- Fork Tilt Down: 2.82sFort Tilt Up: 3.01s
