Standard Equipment
- Manufactured from High Quality QSt/E Steel
- Headstock Cat. I + II for Rear mounting
- Mountable in two positions variable by 30cm (Offset)
- Gearbox with integrated over run clutch and through drive 540 r.p.m. or 1000 r.p.m.
- Belt protection with tension measuring slot
- Stand
- High tempered “M” Hammer flails
- Smooth running Spiral rotor with specially formed lugs
- Patented removable shredding bar – System: “Shark Fin”
- Roller to carry the flail, adjustable for different heights
- High tempered spring steel one way protection flaps in front of the mower
- Optimised distance between the outer rotor circle and the roller guarantees perfect contour following and an even quality of cut
- P.T.O. shaft and Guarding to ISO Standards
Options
- Warning signs and lights (dealer fit)
Technical Data
| MODEL |
WW (cm) |
OVERALL
WIDTH (cm) |
MAX. TRACTOR HP
(540 r.p.m /
1000 r.p.m) |
Weight
(kg) |
NO. OF FLAILS |
| MU-ECOTOP 160 |
160 |
177 |
60 / 75 |
350 |
14 |
| MU-ECOTOP 180 |
180 |
197 |
60 / 75 |
365 |
16 |
| MU-ECOTOP 200 |
200 |
217 |
60 / 75 |
380 |
16 |
