Motor Graders 24Get latest price

KEY SPECS

• Net Power - EEC 80/1269
  • 399 kW
• Weight*
  • 73344 kg
• Blade Width
  • 7.3 m

ENGINE

• Net Power - EEC 80/1269399 kW
• Bore137.2 mm
• Stroke152.4 mm
• Note (1)Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 Standards in effect at the time of manufacture.
• Note (3)Net power advertised is the power available at rated speed of 1,800 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator.
• Note (2)Optimized VHP Plus is standard for the 24.
• Standard Capability50 °C
• EmissionsTier 4 Final/Stage IV or Equivalent to Tier 2/Stage II
• Note (4)Power as declared per ISO 14396. Rated rpm 1,800 (561 hp)
• Engine ModelCat C27
• Displacement27.03 l
• Number of Cylinders12

MACHINE WEIGHT

• Weight*73344 kg

MOLDBOARD

• Blade Width7.3 m
• Blade Height1025 mm
