APPLICATION

• Suitable for use with clean water and with liquids that are not chemically aggressive towards the materials from which the pump is made. As a result of their quietness these pumps are widely used in domestic applications such as the distribution of water in combination with small and medium sized pressure tanks, and for the irrigation of gardens and orchards, etc. The pump should be installed in an enclosed environment or sheltered from inclement weather.

FEATURES

• TISSEL 200 are compact pumping units consisting of one centrifugal
• waterpump coupled with a variable speed device(inverter) with an external pressure sensor to be placed in a place inside the system.
• Sturdy and simple to use,TISSEL 200 is ideal to keep always constant pressure inside system regardless variation of utilities.
• Built-in speed regulator with automatic fan ventilation and IP54 protection. Powered by single-phase alternate tension(230±10% V - 50/60 Hz) it gives an output alternate 3phase tension to run waterpump motor in IE3 class.
• Smooth start and stop of the pump .
• Lower wear of the waterpump due to modulation of running speed from the inverter.

CONSTRUCTION

• PUMP BODY Stainless steel AISI 304 complete with threaded ports in compliance with ISO 228/1
• BODY BACKPLATE Stainless steel AISI 304
• IMPELLERS Noryl
• DIFFUSERS Stainless steel AISI 304
• MOTOR SHAFT Stainless steel AISI 431
• MECHANICAL SEAL
• Seal Model FN-18
• Shaft Diameter Ø 18 mm
• Materials
• Stationary ring Graphite
• Rotational ring Ceramic
• Elastomer NBR
