Dumpmaster HD Electric Bin Lifter | DM0700, DM1200, DM1500, DM1800

Name: Dumpmaster HD Electric Bin Lifter | DM0700, DM1200, DM1500, DM1800
Brand: Emoveit

Supplier: Emoveit

The Dumpmaster safely empties any kind of bin at any height, with a unique electro-hydraulic mechanism that can lift and tip more than 250kg.

Heavy-duty electric lifter

The Dumpmaster HD Electric Bin Lifters DM0700, DM1200, DM1500, and DM1800 are powerful battery-operated solutions designed for safe and efficient bin lifting and dumping. These electric bin lifters enhance workplace safety by minimizing manual handling of heavy bins. Built for durability, the Dumpmaster HD series delivers reliable performance across various industrial and commercial settings. Their heavy-duty designs ensure smooth and controlled bin dumping to streamline waste management processes. Upgrade your facility with the Dumpmaster HD electric bin lifters for efficient, safe, and versatile waste handling.

The Dumpmaster is the safest, fastest and most reliable bin tipper on the market, and has been continuously improved over more than thirty years.

Dumpmaster bin tippers are very versatile and are used in dozens of applications; from emptying rubbish bins into skips to pouring food ingredients into mixers. They feature a unique tipping action which lifts the bin straight up, then gently rolls it upside down over the lip of the receptacle. Less than 1m3 of floor space is required regardless of tipping height, since the weight of the bin is maintained within the floor footprint at all times.

The Dumpmaster was designed for safety, with full guarding and door interlock systems fitted as standard. The machine can be optionally certified to various standards, including ISO 12100, AS/NZS 4024, and CE.

No matter how it is used, the Simpro Dumpmaster has proven to be safe, reliable and economical to operate, year after year.

Dumpmaster Options and Accessories

Power supply: battery, 1-phase, 3-phase, or compressed air
Dockmaster variant, optimised for emptying bins from elevated loading docks and platforms.
Solar panel
Full or partial 304 stainless steel construction
Frame-mounted tipping chute
Bin hook kit to secure machine in position
Customised cradles to suit virtually any type of bin or drum
Left-hinge, right-hinge, swing-up or roller door
ISO13849-1 and AS/NZS4024 Cat3/PLd or Cat4/PLe safety monitoring system
Emergency Stop button(s)
Corrosion-resistant nickel-plated lifting chains
Dual side covers and dual controls
'Door end' or pendant controls
Transparent, unbreakable polycarbonate guarding
Polycarbonate operator guard (splash shield)
Sheet metal guarding
Foot-guard panels
Safety-certified door latches and componentry
Auto-cycle controller
Digital scales for weighing bins

Dumpmaster Specifications:

Model	DM0700*	DM1200	DM1500	DM1800	DM2100	DM-CUSTOM
Tipping height (“TH”)	700mm	1200mm	1500mm	1800mm	2100mm	xxxx mm
Height (“OH”)	1770mm	2260mm	2560mm	2860mm	3160mm	xxxx + 1060mm
Guarding height (“GH”)	1755mm	2200mm
Width	964mm
Length (door closed / open)	1170mm / 1834mm
Weight	~160kg	~205kg	~215kg	~225kg	~235kg	xxxx / 30 + 165kg
Capacity (max bin weight)	250kg
Bin compatibility (standard cradle)	60L, 80L, 120L, 140L, 240L EN840 wheelie bins (options: custom cradle)
Bin throw (“BT”)	~100mm (with 240L wheelie bin)
Electrical specifications (battery power)	Onboard digital float charger (input: 85-264VAC 47-63hz, max draw 3 Amps), with 2x 12V 21Ah deep-cycle sealed gel batteries in series configuration, 0.8kW DC electric motor, and 24VDC control circuit (options: solar panel)
Electrical specifications (1-phase power)	1-phase mains supply (120/240VAC 50-60hz, max draw 8 Amps), with Variable Speed Drive (VSD) controller driving 0.75kW AC electric motor, and 24VDC control circuit
Electrical specifications (3-phase power)	3-phase mains supply (380-415VAC 50-60hz, max draw 1.9 Amps), with 0.75kW AC electric motor, and 24VDC control circuit
User interface	Raise/Lower buttons, key switch, battery indicator, master lockout switch (options: VSD joystick, autocycle unit with Emergency Stop button)
Ingress protection	IP55 (options: IP56, IP66, IP69K)
Cradle travel speed (lifting / lowering)	0.4m/s / 0.28m/s
Tipping cycle duration	~8s	~11s	~13s	~15s	~17s	xxxx / 166 + 4s
Sound level at operator’s ear	≤ 60dB
Materials	Hot-dip galvanised mild steel frame, galvanised mild steel cradle, 25x25x2.5mm zinc-plated wire mesh guarding (options: sheet metal guarding, polycarbonate guarding, full or partial 304 or 316 stainless steel)
Door	Left-hinged door with solenoid-operated electrical safety interlock (options: right-hinged door, swing-up door, roller door)
Wheels	?100mm Blue Resilex castors (options: ?200mm castors, bolt-down lugs)
Applicable Standards and Certifications	AS/NZS4024, ISO 13849-1, IEC 62061, Conformité Européene (CE), EN 349 1993, EN 574 1996+A1:200, EN 953 1997, EN ISO 4413 2010, EN ISO 12100 2010, EN ISO13849-1 2006, EN ISO 13857 2008, EN 60204 2006+A1 2009, EN61000-6-2 2005, EN61000-6-4 2007, Machinery Directive 2006/42/EC, Electromagnetic Compatibility Directive 2004/108/EC
