Conveyor Rollers | Composite Rollers

Name: Conveyor Rollers | Composite Rollers
Brand: Veyex | Conveying Excellence

Supplier: Veyex | Conveying Excellence

Composite Rollers are the next generation in conveyor rollers designed to provide high performance and durability, whilst weighing up to 60% less than conventional steel rollers.

Composite Rollers are available in a range of materials including HDPE, CF-HDPE, UHMWPE, ECO-HDPE, FLAME RESISTANT and FRAS material approved for use in underground* applications.

Unlike our competitors rollers which use press in end caps, the Composite Rollers are the only composite roller with a friction welded end cap. The friction welding process binds the housing to the shell, effectively welding the shell together, increasing the structural integrity of the conveyor roller and eliminating a common failure point on existing composite rollers in the market today.

Product Features:

Friction Welded End Caps
Bearings range from 6205 – 6312
Hollow shaft options for rollers with face lengths of 600mm+
Complete range of roller sizes from 89-250mm in diameter
Energy efficient (low breakaway mass)
High quality 2RS or 2ZZ bearings
Exceptional balance – ISO1940 G16
Range of composite materials to suit a range of applications
Low noise Manufactured in accordance with ISO9001 and CEMA specifications.

Operational Benefits:

Up to five times longer operational life over steel rolls.
Substantial reduction in system power requirements.
Ave 10dB drop in sound emissions over steel rolls.
Longevity of composite rolls will dramatically improve conveyor conveyor uptime and productivity.
Smart component configuration has improved overall operational performance over competitor conveyor rolls.

Financial Benefits:
