Manitou MLT-X 961-160 V+ L Agricultural Telescopic handler
Description
Documents
In Stock
The MLT 961-160 V+ L has a 9 m lifting height, a 6 t max. capacity and a M-Vario Plus transmission. It offers even more comfort, performance and cost efficiency. For your comfort, the machine is equipped as standard with a ultra-quiet NewAg XL cab, an "easy step" access, a high visibility grid, an automatic parking brake, a cup holder, a full range of storages, optional adaptive air suspension seat... Designed for heavy duty applications with a power of 156 hp and a max. torque of 805 Nm, this telehandler has an air prefilter and an auto reversing fan. These features are perfectly adapted to dusty environments. The 200 l/min load sensing pump and the optional Intelligent Hydraulics package answer customers needs in terms of performances in agriculture and agro-industry. In terms of profitability, the MLT 961 combines easy maintenance (centralized position of greasing points, self cleaning air prefilter, connected machine, automatic greasing system option) and fuel consumption optimization (Eco mode, Ecostop / Regenerative Hydraulics options...) for an optimal total cost of ownership.
TECHNICAL FEATURES
Capacities:
capacity
6000 kg
lifting height
9 m
outreach
30 m
Reach at max. height
10 m
Breakout force with bucket
7300 daN
Weight and dimensions:
Unladen weight (with forks)
11950 kg
Ground clearance
45 m
Wheelbase
3 m
Overall length to carriage (with hitch)
10 m
Front overhang
65 m
Overall width
48 m
Overall cab width
99 m
Overall height
55 m
Tilt-down angle
135 °
Tilt-up angle
12 °
External turning radius (over tyres)
30 m
Standard tyres
Alliance - A580 - 500/70 R24 164A8
Drive wheels (front / rear)
2 / 2
Steering wheels (front / rear)
2 / 2
Frame levelling corrector
7 °
Performances
Lifting
50 s
Lowering
50 s
Extension
7 s
Retraction
6 s
Crowd
80 s
Dump
60 s
Engine
Engine brand
Yanmar
Engine norm
Stage IIIA
fuel sulphur content
1000 ppm
Engine model
4TN107TT-5SMUF
Number of cylinders - Capacity of cylinders
4 - 4567 cm³
C. Engine power rating / Power (kW)
156 Hp / 115 kW
torque / Engine rotation
805 Nm @1350 rpm
Drawbar pull (Laden)
9700 daN
Reversible fan
Standard
Engine cooling system
3 radiators water + intercooler + transmission oil
Transmission
Transmission type
M-Vario Plus
travel speed (may vary according to applicable regulations)
40 km/h
Parking brake
Automatic negative parking brake
Service brake
Oil-immersed multi-discs braking on front & rear axles
Hydraulic
Hydraulic pump type
Load sensing pump
Hydraulic flow - Pressure
150 l/min - 270 bar
Flow sharing distributor
Standard
Tank capacities
Hydraulic oil
180 l
Fuel tank
142 l
Noise and Vibaration
Noise at driving position (LpA) tested following NF EN 12053 norm
